OGT-2
YUXI
Description
This tester is used for testing the linear velocity of governor tension pulley and response time of governor tripping. It is suitable for on-site inspection of lift governor by testing companies, lift installation and maintenance departments etc, as well as online testing of lift and overspeed governor manufacturers.
Functions
Integrated with driving, test, display and data storage in one tester. Operate easily.
Colour touch screen control.
Testing response time of electric safety device and safety gear. Record test results.
Driver rotating direction is adjustable. (clockwise and anti-clockwise)
Governor parameter settingl
Data viewing, deletion and browsing
Clock function
Data export function: test result can be exported to PC(by software) for saving and printing
Bluetooth printing
Parameter
Linear velocity range: 0.2-6m /s
Rotating speed range: 1-9999rpm
Accuracy: ﹤±1%
Display:3 inch Touch screen
Data memory: 1000 groups
Power: DC 29.4V
Maximum speed of drive motor: 3000rpm
Range of acceleration:0.01-0.05m/s2
Bluetooth transmission distance: ≤10m
